1. Products Introduction
The pneumatic actuated PVDF true union ball valves from Sanking is typically suitable to higher temperature services, extreme corrosive and sensitive media systems. The R & D pays great attention to product details and user experience. Its surface of Pneumatic actuated PVDF true union ball valves are made by plastic including its pneumatic actuator, innovation bracket and valves. Compact design,more friendly to the tighten installation space. The thread on the body of PVDF true union ball valve are reverse teeth, when the nuts are installed, it will not be loosened due to vibration to ensure no leakage. All valves were assembled & tested by experienced technicians and quality checked by an engineer.
The size is providing from 1/2" to 4" . The product has socket ends,trheaded or flanged. Besides CPVC, we also provide PVC, CPVC & PPH.
2. Main Features
a. Pneumatically Actuator- Single Acting or Double Acting are available for choice.
b. Bracket/Adaptor: PPS bracket (Sanking’s Innovation Patent) is the best choice when you are using in the area where is leak or corrosive gases. SUS304 bracket is available to choose as well.
c. Ball Valve- Sanking PVDF true union ball valve with leak free and reliable. The valve body is reserved with standard holes, can be plugged in the electrical actuator as demands. Full Port Design
d. Reversible PTFE Seats
e. Double O-Ring Stem Seals
f. Easily Actuated
g. FPM O-Ring Seals Standard, EPDM upon Request
h. Easy to Maintain Design
i. Long Service Lifetime – High-grade raw material with UV, weather resistance.
j. Friendly to the tight installation place- Compact size, Lightweight
k. Friendly to the harsh working area- Full plastic (The exposed surface)
l. Compatible to the air filter,limit switch and solenoid valves.
m. Working Pressure- PN10
n. CE certificate
o. IP66
3. Parameter
S/N | Material | SIZE | Operating Temperature © | ||||||||
DN (MM) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | ||
Size (Inch) | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" | 4" | ||
DIN | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
ANSI | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
JIS | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
PT | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
NPT | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
BSPF | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
Operating torque (N.M) | 2.00 | 2.50 | 4.00 | 5.00 | 7.50 | 1.00 | 15.00 | 20.00 | 28.00 | ∕ | |
Working Pressure (psi) | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | ||
Note: ֍ stands for the standard products @ stands for on request, if any requirements, please double check with Sanking team. N/A stands for not available | |||||||||||
4. Pneumatic actuator parameter
Pneumatic Actuated Acting Type:DA/Double Acting,NC/Normally Closed,NO/Normally Open | |||||||||
SIZE | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" | 4" |
Control Pressure （Bar） | 4～8 | ||||||||
NAMUR standard Air Interface | G1/4" | ||||||||
Opening cylinder volume L | 0.1 | 0.1 | 0.1 | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.5 |
Closing cylinder volume L | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.8 |
The air consumption depends on the air pressure, switch stroke, the volume and frequency of action. Caculation is as follows: L/min = cylinder volume (open cylinder volume + close cylinder volume)x[supplied air pressure(Kpa) * 101.3] x times/min. | |||||||||
5. Dimension (Unit:mm)
SIZE | d1 | d2 | D | L | L1 | L2 | L3 | P | H | F | M | I | |||||||||
ANSI | DIN | JIS | CNS | ANSI | DIN | JIS | CNS | ANSI /JIS /CNS | DIN | ANSI /JIS /CNS | DIN | ||||||||||
1/2" | (15) | 21.54 | 20.30 | 22.40 | 22.40 | 21.23 | 20.10 | 21.73 | 21.90 | 54.00 | 104.80 | 92.00 | 22.30 | 16.00 | 60.00 | 52.00 | 155.00 | 176.50 | 31.00 | —— | M6 |
3/4" | (20) | 26.87 | 25.30 | 26.45 | 26.40 | 26.57 | 25.10 | 25.69 | 25.90 | 63.00 | 113.00 | 100.00 | 25.50 | 19.00 | 62.00 | 54.00 | 155.00 | 186.00 | 33.00 | —— | M6 |
1" | (25) | 33.65 | 32.30 | 32.55 | 34.50 | 33.27 | 32.10 | 31.70 | 33.90 | 73.50 | 127.20 | 114.00 | 28.60 | 22.00 | 70.00 | 62.00 | 155.00 | 196.50 | 40.00 | —— | M6 |
1-1/4" | (32) | 42.42 | 40.30 | 38.60 | 42.50 | 42.04 | 40.10 | 37.65 | 41.90 | 84.50 | 142.00 | 130.00 | 32.00 | 26.00 | 78.00 | 70.00 | 168.00 | 235.00 | 52.00 | —— | M8 |
1-1/2" | (40) | 48.56 | 50.30 | 48.70 | 48.60 | 48.11 | 50.10 | 47.74 | 47.90 | 98.00 | 157.50 | 151.50 | 35.00 | 32.00 | 87.50 | 79.50 | 168.00 | 249.50 | 52.00 | —— | M8 |
2" | (50) | 60.63 | 63.30 | 60.80 | 60.60 | 60.17 | 63.10 | 59.78 | 59.90 | 118.00 | 171.00 | 38.00 | 95.00 | 85.00 | 168.00 | 280.00 | 70.00 | —— | M8 | ||
2-1/2" | (65) | 73.38 | 75.30 | 76.60 | 76.70 | 72.85 | 75.10 | 75.68 | 75.90 | 150.00 | 238.50 | 47.00 | 144.50 | 132.50 | 219.00 | 331.00 | 84.00 | 45.00 | M10 | ||
3" | (80) | 89.31 | 90.40 | 89.60 | 89.70 | 88.70 | 90.10 | 88.55 | 88.90 | 169.00 | 268.00 | 51.00 | 166.00 | 150.00 | 249.00 | 362.50 | 84.00 | 45.00 | M10 | ||
4" | (100) | 114.76 | 110.40 | 114.70 | 115.00 | 114.10 | 110.10 | 113.60 | 113.80 | 211.00 | 318.00 | 61.00 | 196.00 | 172.00 | 249.00 | 423.00 | 121.00 | 49.00 | M12 | ||
6. Application
The pneumatic actuated pvdf true union ball vale has been Used in petroleum refining, long-distance pipelines, ultrapure water, metallurgical pickling, electronics, semiconductors, chemicals, shipbuilding, chlor-alkali, medicine, environmental protection and other fields.
6. Our Advantage
Our advantages are professional designs, best quality control,punctual delivery ,good communication and reasonable prices.
(1) We operates our own factory with progressive equipments
(2) Since we have our own factory we can offer you the most competitive prices and quality saving the agent fees and reducing the cost for you.
(3) We have a strict and professional QC team, each model is being checked prior to delivery to insure our high standards and quality.
(4) We believe every order deserves personal attention and are detected to make every order and reorder experience to be fast, smooth, and error free.
7. Certificates
Our company has been audited and approved CE certification.
