Xiamen Sanideng Plastics Industry Co., Ltd. is one of the most reliable manufacturers and suppliers of pvdf true union diaphragm valve in China. With abundant experience, we warmly welcome you to wholesale premium pvdf true union diaphragm valve for sale here from our factory. Quality products and reasonable price are available.
1. Products Introduction
The structure of PVDF diaphragm valve is not the same as that of general valves. It is a new type of valve and a special form of shut-off valve. Its opening and closing part is a diaphragm made of soft material, which connects the valve body cavity with the The inner cavity of the valve cover is separated from the driving parts. Since the working medium is only in contact with the diaphragm and the valve body, both of which can be made of a variety of different materials, the valve can ideally control a variety of working media, especially for media with chemical corrosives or suspended particles. The valve is easy to disassemble and repair quickly, and the replacement of the diaphragm can be done on site and in a short time. Due to the fact that PVDF materials do not contain plasticizers, pigments or other additives, they are also excellent in chemical resistance and impact resistance, making PVDF diaphragm valves suitable for medical, pharmaceutical, cosmetic and other industries that need to transport high-purity liquids.
We provide the size from 1/2" to 4", the joint end has the socket,thread and flanged. ANSI,JIS and DIN are available. For the socket connection, it can be fusion or butt weld.
2. Main Features
a. The herringbone flow channel is suitable for media containing particles and is not easy to be stuck.
b. The wheel-shaped handle with multiple turns, can more accurately adjust the valve switch ratio to achieve better flow control
c. Excellent seal – The diaphragm is made from resistant thermoplastic material: EPDM, FPM or PTFE which is high-grade, stretching and creep materials. Double-layer diaphragms can be chose when used for harsh working conditions with chemically to improve the chemical resistance and life of the valve.
d. Long Service Lifetime – Made by nano molded material with UV, weather resistance
e. 100% Leak free inspection
f. Working Pressure- PN10
g. CE certificate
3. Parameter
S/N | Material | SIZE | Operating Temperature © | ||||||||
DN (MM) | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | ||
Size (Inch) | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" | 4" | ||
DIN | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
ANSI | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
JIS | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
PT | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
NPT | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
BSPF | PVC-U | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 55 ℃ |
PVC-C | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PPH | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | 5 ℃ - 95 ℃ | |
PVDF | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | ֍ | - 20 ℃ - 150 ℃ | |
Operating torque (N.M) | 2.00 | 2.50 | 4.00 | 5.00 | 7.50 | 1.00 | 15.00 | 20.00 | 28.00 | ∕ | |
Working Pressure (psi) | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 | ||
Note: ֍ stands for the standard products @ stands for on request, if any requirements, please double check with Sanking team. N/A stands for not available | |||||||||||
4. Dimension (Unit:mm)
SIZE | d1 | d2 | D | L1 | L | H | |||||||||
ANSI | DIN | JIS | CNS | ANSI | DIN | JIS | CNS | ANSI /JIS /CNS | DIN | ANSI /JIS /CNS | DIN | ||||
1/2" | (15) | 21.54 | 20.30 | 22.40 | 22.40 | 21.23 | 20.10 | 21.73 | 21.90 | 54.00 | 22.30 | 16.00 | 142.60 | 130.00 | 154.50 |
3/4" | (20) | 26.87 | 25.30 | 26.45 | 26.40 | 26.57 | 25.10 | 26.69 | 25.90 | 63.00 | 25.50 | 19.00 | 159.00 | 146.00 | 163.50 |
1" | (25) | 33.65 | 32.30 | 32.55 | 34.50 | 33.27 | 32.10 | 31.70 | 33.90 | 73.50 | 28.60 | 22.00 | 185.20 | 172.00 | 178.20 |
1-1/4" | (32) | 42.42 | 40.30 | 38.60 | 42.50 | 42.04 | 40.10 | 37.65 | 41.90 | 84.50 | 32.00 | 26.00 | 246.00 | 234.00 | 254.00 |
1-1/2" | (40) | 48.56 | 50.30 | 48.70 | 48.60 | 48.11 | 50.10 | 47.74 | 47.90 | 98.00 | 35.00 | 32.00 | 252.00 | 246.00 | 261.00 |
2" | (50) | 60.63 | 63.30 | 60.80 | 60.60 | 60.17 | 63.10 | 59.78 | 59.90 | 118.00 | 38.00 | 287.00 | 294.00 | ||
2-1/2" | (65) | 73.38 | 75.30 | 76.60 | 76.70 | 72.85 | 75.10 | 75.68 | 75.90 | 150.00 | 47.00 | 359.60 | 371.00 | ||
3" | (80) | 89.31 | 90.40 | 89.60 | 89.70 | 88.70 | 90.10 | 88.55 | 88.90 | 169.00 | 51.00 | 409.00 | 400.00 | ||
4" | (100) | 114.76 | 110.40 | 114.70 | 115.00 | 114.10 | 110.10 | 113.60 | 113.80 | 211.00 | 61.00 | 494.00 | 440.00 | ||
5. Application
The PVDF True Union Diaphragm Valve is mainly used in food processing industry, beverage processing industry, IC semiconductor industry, chemical industry, etc.
6. Our advantage
45 years experience
In the market since 1976 and still growing, now internationally.
Highly qualified team
Quality of our products is the reflection of our team's skills.
Customer satisfaction
From creative process, until concepts come to life our aim is customers' satisfaction.
7. Certificates
Our company has been audited and approved CE certification.
8. FAQ
Q1: Are samples available to be sent with free?
A: It depends on what product you need. There are hundreds of products we sell. You can contact us for particular answer.
Q2: How to guarantee the high quality?
A: We have testing department to make sure quality of every product, appearance, flow and pressure test are good.
Q3: How about your delivery time?
A: Generally, 2-3 days for the conventional product in stock after receiving your payment. The specific delivery time depends on the items and the quantity of your order.
Q4: Why Choose us?:
A: Firstly, comparing with many factories, our price are more competitive.
Secondly, We 100% test working pressure for ALL our products.
Finally, After-Sale Services will be highly satisfied. Any problems and feedbacks will be responded efficiently.
